IDEC SmartRelay Manual 297
A
Technical data
A.1 General technical data
Criterion
Tested in accordance with
Values
IDEC SmartRelay Base
Dimensions (WxHxD)
Weight
Installation
72 x 90 x 55 mm
Approx. 190 g
on a 35 mm profile rail
4 module widths
or wall mounting
IDEC SmartRelay
expansion modules
Dimensions (WxHxD)
Weight
Installation
36 x 90 x 53 mm
Approx. 90 g
on a 35 mm profile rail
2 module widths
or wall mounting
Text Display 128.2 x 86 x 38.7 mm
Approx. 220g
Bracket mounting
Climatic conditions
Ambient temperature
Horizontal installation
Vertical installation
Low temperature to IEC
60068-2-1
High temperature to IEC
60068-2-2
0 ... 55 °C
0 ... 55 °C
Storage/shipping -40 °C ... +70 °C
Relative humidity IEC 60068-2-30 From 10 to 95 %
no condensation
Air pressure 795 ... 1080 hPa
Pollutants IEC 60068-2-42
IEC 60068-2-43
SO
2
10 cm
3
/m
3
, 10 days
H
2
S 1 cm
3
/m
3
, 10 days
Ambient mechanical conditions
Degree of protection IP 20 for IDEC SmartRelay
base module front panel
IP 65 / UL type 4x / 12 for
Text Display front panel
Vibrations: IEC 60068-2-6 5 ... 8.4 Hz
(constant amplitude
3.5 mm)
8.4 ... 150 Hz
(constant acceleration 1 g)
Shock IEC 60068-2-27 18 shocks
(half-sine wave 15g/11 ms)
Free fall (packaged) IEC 60068-2-32 0.3 m
