Technical data
298 IDEC SmartRelay Manual
Note: Use a surge absorber, noise cut transformer, or noise filter to protect products
rated at 12/24V DC or 24V DC power type modules against surge.
Electromagnetic compatibility (EMC)
Noise emission EN 55011/A
EN 55022/B
EN 50081-1
(domestic area)
Limit class B group 1
Electrostatic discharge IEC 61000-4-2
Severity 3
8 kV air discharge
6 kV contact discharge
Electromagnetic fields IEC 61000-4-3 Field strength 1 V/m and 10
V/m
HF currents on cables and
cable shielding
IEC 61000-4-6 10 V
Burst pulses IEC 61000-4-4
Severity 3
2 kV (supply and signal
lines)
High-energy surge pulse
(applies only to
FL1E-H12RCC/
FL1E-B12RCC)
IEC 61000-4-5
Severity 3
1 kV (power lines)
symmetrical
2 kV (power lines)
asymmetrical
Safety to IEC
Clearance and creepage
distance rating
IEC 60664, IEC 61131-2,
EN 50178
cULus to UL 508, CSA
C22.2 No. 142
With FL1E-H12RCC/
FL1E-B12RCC, also
IEC60730-1
Fulfilled
Insulation strength IEC 61131-2 Fulfilled
Cycle time
Cycle time per function < 0.1 ms
Startup
Startup time at power-up typ. 9 s
Criterion
Tested in accordance with
Values
