IDEC SmartRelay installation and wiring
IDEC SmartRelay Manual 25
2.2 Installing/removing IDEC SmartRelay
Dimensions
The IDEC SmartRelay installation dimensions are compliant
with DIN 43880.
IDEC SmartRelay can be snap–mounted to 35 mm DIN rails
to EN 50022 or on the wall.
IDEC SmartRelay width:
• Text Display has a width of 128.2 mm, which corresponds
to 8 subunits
• IDEC SmartRelay base modules have a width of 72 mm,
wh
ich corr
esponds to 4 subunits
• IDEC SmartRelay expansion modules have a width of
36 mm, which corresponds to 2 or 4 subunits
Note
The figure below shows you an example of the installation and
removal of a FL1E-H12RCC and a digital module. The measures
shown apply to all other IDEC SmartRelay Base versions and
expansion modules
