IDEC SmartRelay functions
150 IDEC SmartRelay Manual
If retentivity is not set, output Q and the expired time are
reset after a power failure.
Setting the Par parameter
Note the defaults specified in Chapter 4.3.2.
Note
T, T
!
and T
!L
must all have the same timebase.
View in programming mode (example):
B5 1+R
T =60:00s
TL =10:00s
Protection mode and retentivity
Off-delay
Permanent light on-time
B5 2
T! =30:00s
T!L =20:00s
Start of the off-warning period
(T - T!)
Off-warning time
View in parameter assignment mode (example):
B5 1
T =60:00s
TL =10:00s
Ta =06:00s
Current value of the time T
L
or T
4.4.11 Seven-day time switch
Short description
The output is controlled by means of a configurable on/off
date. Th
e function supports any combination of weekdays.
You select the active weekdays by hiding the inactive days.
