2.4 Putting into operation
2.4.1 Switching on the IDEC SmartRelay/Power On
IDEC SmartRelay does not have a power switch. The
reaction of IDEC SmartRelay during startup depends on the
following:
• Whether a circuit program is stored in IDEC SmartRelay
• Whether a memory cartridge or combined memory/
batter
y car
tridge is inserted
• Whether this is an IDEC SmartRel
ay version without
display unit (FL1E-B12...)
• The status of IDEC SmartRelay at the tim
e of power
failure.
All possible reactions of IDEC SmartRelay are described on
the following
page.
To ensure that the expansion module on IDEC SmartRelay
changes to RUN mod
e, check the following:
• Has the sliding contact between IDEC SmartRelay and
the expansion
module snapped into place properly?
• Is the power supply connected to the expansion module?
• In addition, always ensure that you switch on the power
su
pply to the
expansion module first before activating the
power supply to the IDEC SmartRelay base module (or
activate both power supplies at the same time); if you do
not do this, the system does not detect the expansion
module when you start up the IDEC SmartRelay base
module.
Note
After power-up, the FL1E performs initialization. After completing
initialization, the FL1E is ready to start to run. During initialization,
a sandglass is displayed on the CPU module with display, or the
LED is lit red on the CPU module without display.
Initialization time (regardless of expansion module)
When a memory cartridge or a combined memory/battery cartridge
is installed: Max. 10 sec
When a cartridge is not installed or when a battery cartridge is
installed: Max. 9 sec
*The initialization time depends on the program size.
