IDEC SmartRelay functions
IDEC SmartRelay Manual 213
Parameter Level 1 and Level 2:
Levels to be reached
Range of values for each level:
-10,000 to +20,000
MaxL:
Maximum value that must not be
exceeded under any
circumstances.
Range of values:
-10,000 to +20,000
StSp:
Start/Stop offset:
value that is added to Offset ”B”
to create the start/stop level. If the
Start/Stop offset is 0, then the
start/stop level is Offset ”B”..
Range of values:
0 to +20,000
Rate:
Acceleration with which level 1,
level 2 or Offset is reached.
Steps/seconds are issued.
Range of values:
1 to 10,000
A: Gain
Range of values: 0 to 10.00
B: Offset
Range of values: 10,000
p: Number of decimals
Range of values: 0, 1, 2, 3
Output AQ The output AQ is scaled using the
formula:
Range of values for AQ:
0 to +32767
(Current Level - Offset ”B”)/ Gain ”A”
Range of values:
0 to +32767
Note:
When AQ is displayed in parameter
mode or message mode, it is
displayed as an unscaled value
(engineering units: current level).
Symbol in IDEC
SmartRelay
Wiring Description
