IDEC SmartRelay functions
IDEC SmartRelay Manual 217
Parameter SP: Set-value assignment
Range of values:
-10,000 to +20,000
KC: Gain
Range of values:
00.00 to 99.99
TI: Integral time
Range of values:
00:01 to 99:59 m
Dir: Action direction of the controller
Range of values:
+ or -
Mq: Value from AQ with manual
mode
Range of values:
0 to 1000
Min: Minimum value for PV
Range of values:
-10,000 to +20,000
Max: Maximum value for PV
Range of values:
-10,000 to +20,000
A: Gain
Range of values:
10.00
B: Offset
Range of values:
10,000
p: Number of decimals
Range of values:
0, 1, 2, 3
Output AQ This special function has an analog
output (= manipulated variable). This
output can only be connected with the
analog input of a function, an analog
memory marker or an analog output
connector (AQ1, AQ2).
Range of values for AQ:
0...1000
Symbol in IDEC
SmartRelay
Wiring Description
