IDEC SmartRelay functions
IDEC SmartRelay Manual 221
Setting the Par parameter
View in programming mode (example):
B3 1+/
SP
B020
B3 2+/
KC =10.00
TI =01:00
Dir=+
B3 4+/
A =02.50
B =–00300
p=0
B3 2+/
KC =10.00
TI =01:00
Dir=+
B3 3+/
Mq
B021
Min=–05000
Max=+05000
Press
Press
Press
View in parameter assignment mode:
B3 1
SP
B020
PV = 0
AQ =+0250
B3 2
KC =10.00
TI =01:00
Dir=+
B3 4
A =02.50
B =–00300
B3 3
Mq
B021
Min=–05000
Max=+05000
Press
Press
Press
