IDEC SmartRelay functions
228 IDEC SmartRelay Manual
Examples
The following tables show some simple example analog
math block parameters, and the resulting equations and
output values:
Equation: (
12
+ (6 / 3)) - 1
Result: 13
Equation: 2 + (3 * (1 + 4))
Result: 17
Eq
uation: (100
- 25) / (2 + 1)
Result: 25
V1 Op1(Pr1) V2 Op2(Pr2) V3 Op3(Pr3) V4
12 + (M) 6 / (H) 3 - (L) 1
V1 Op1(Pr1) V2 Op2(Pr2) V3 Op3(Pr3) V4
2 + (L) 3 * (M) 1 + (H) 4
V1 Op1(Pr1) V2 Op2(Pr2) V3 Op3(Pr3) V4
100 - (H) 25 / (L) 2 + (M) 1
