IDEC SmartRelay memory and battery cartridge (card)
IDEC SmartRelay Manual 257
When IDEC SmartRelay has finished copying, it opens the
main menu:
>Program..
Card..
Setup..
Start
Note
Before you switch IDEC SmartRelay to RUN, you must ensure that
the system you are controlling with IDEC SmartRelay does not
represent a source of hazard.
1. Move the ’>’ cursor to ’Start’: Press or
2. Press OK.
Copying by means of the “Card”menu
For information on the replacement of a memory cartridge or
comb
ined m
emory/battery cartridge, also note Chapter 6.2.
To copy a program from the memory cartridge or combined
me
mory/ba
ttery cartridge to IDEC SmartRelay:
1. Insert the memory cartridge or combined memory/battery
cartridge
2.
Switch IDEC SmartRelay to programming mode (ESC /
>Stop).
>Program..
Card..
Setup..
Start
3. Move the ’>’ cursor to ’Card’: Press or
4. Press OK. The transfe
r menu opens.
