IDEC SmartRelay software
260 IDEC SmartRelay Manual
WindLGC
WindLGC runs under Windows 7
®
, Windows Vista
®
,
Windows 98
®
, Windows NT 4.0
®
, Windows Me
®
, Windows
2000
®
, Windows XP
®
. WindLGC is capable of client/server
operation and offers you a high degree of freedom and
comfort for creating your circuit program.
WindLGC V6.2
This is the current version of WindLGC. You will find
all the
functions and the functionality of the devices described in
this manual in the version 6.2.
Note
Please note that the SmartRelay ladder programming is slightly
different from PLC programming.In the case of a PLC, the output
result on each line is reflected on the inputs within the same scan
time. However, in the case of the IDEC SmartRelay, all the inputs
are processed first and then the outputs. Thus the output results are
not reflected on the inputs within the same scan time, but rather
they are reflected at the following scan.
ex) Interlock is not activated in the sample program (1) below in
which input terminals I1 and I2 are simultaneously turned on. The
interlock is activated in the sample program (2) below in which input
terminals I1 and I2 are simultaneously turned on.
