Technical data
310 IDEC SmartRelay Manual
Digital inputs
Number 8,
optional P action or N action
Electrical isolation No
High speed inputs not applicable for this module
Input frequency
• Normal input
• High speed input
• max. 4 Hz
• not applicable for this module
Input voltage
• Signal 0
• Signal 1
L
< 5 V AC/DC
> 12 V AC/DC
Input current at
• Signal 0
• Signal 1
< 1.0 mA
> 2.5 mA
Delay time at
• 0 to 1
• 1 to 0
typ. 1.5 ms
typ. 15 ms
Line length (unshielded) 100 m
Analog inputs
Number
Range
max. Input voltage
Digital outputs
Number 4
Output type Relay outputs
Electrical isolation Yes
Dielectric Strength (between power/input
terminals and output terminals)
2,500 V AC, 1minute
500 V DC, 1 minute
In groups of 1
Control of a digital input Yes
Continuous current I
th
max. 10 A per relay
Surge current max. 30 A
Incandescent lamp load
(25000 switching cycles) at
1000 W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W
Fluorescent tubes, conventionally
compensated (25000 switching cycles)
1 x 58 W
FL1E-H12RCA
FL1E-B12RCA
