Technical data
316 IDEC SmartRelay Manual
Notice: For fluorescent lamps with capacitors, the technical data of fluorescent lamp
ballasts must also be considered. If the maximum allowed surge current is exceeded,
fluorescent lamps must be switched with appropriate contactor relays.
(1): 8 V DC (Version 1 to 5 specifications)
(2): 1.0 mA (Version 1 to 5 specifications)
Short circuit-proof cos 0.5 to 0.7 Power protection B16,
900A
Power protection B16,
900A
Parallel output circuits for power
increase
Not permitted Not permitted
Protection of output relay
(if desired)
max. 16 A,
characteristic B16
max. 16 A,
characteristic B16
Minimum Switching Load 10 mA, 12 V DC 10 mA, 12 V DC
Initial Contact Resistance
100 mmaximum
(at 1A, 24V DC)
100 m maximum
(at 1A, 24V DC)
Mechanical Life
10,000,000
operations minimum
(no load, 10 Hz)
10,000,000
operations minimum
(no load, 10 Hz)
Electrical Life
100,000 operations
minimum (rated
resistive load, 1800
operations / hour)
100,000 operations
minimum (rated
resistive load, 1800
operations / hour)
Switching rate
Mechanical 10 Hz 10 Hz
Ohmic load/lamp load 2 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz
FL1E-H12RCE
FL1E-B12RCE
FL1B-M08B2R2
