IDEC SmartRelay installation and wiring
IDEC SmartRelay Manual 31
Note
The number of supplied mounting screws and brackets on the
FL1E-RD1 text display depends on the version. The version
number of the FL1E-RD1 is found in the lower-right corner on the
back of the module. For identifying the version, see page 5.
For versions 3 and earlier, 2 screws and brackets are provided.
For versions 4 and later, 4 screws and brackets are provided. Listed
by UL type 4x / 12 for a tightening torque of 0.2 Nm.
