Intel® Server Board S1200BT Service Guide 85
0xF0 O O O O X X X X PEIM which detected forced Recovery
condition
0xF1 O O O O X X X O PEIM which detected User Recovery
condition
0xF2 O O O O X X O X Recovery PEIM (Recovery started)
0xF3 O O O O X X O O Recovery PEIM (Capsule found)
0xF4 O O O O X O X X Recovery PEIM (Capsule loaded)
Progress Code
Diagnostic LED Decoder
O = On, X=Off
Upper Nibble Lower Nibble
MSB 8h 4h 2h 1h 8h 4h 2h 1h LSB
#7 #6 #5 #4 #3 #2 #1 #0
Description

Intel S1200BT Specifications

General

Chipset	Intel C204
Socket	LGA 1155
Form Factor	ATX
Memory Type	DDR3
Max Memory	32 GB
Memory Slots	4
PCIe x16 Slots	1
PCIe x4 Slots	1
PCI Slots	2
SATA Ports	6
Ethernet Ports	2
PCIe x8 Slots	1
Network	Intel 82574L
RAID Support	0, 1, 5, 10
