84 Intel® Server Board S1200BT Service Guide
0x95 O X X O X O X O DXE PCI Bus resource requested
0x96 O X X O X O O X DXE PCI Bus assign resource
0x97 O X X O X O O O DXE CON_OUT connect
0x98 O X X O O X X X DXE CON_IN connect
0x99 O X X O O X X O DXE SIO initialization
0x9A O X X O O X O X DXE USB start
0x9B O X X O O X O O DXE USB reset
0x9C O X X O O O X X DXE USB detect
0x9D O X X O O O X O DXE USB enable
0xA1 O X O X X X X O DXE IDE begin
0xA2 O X O X X X O X DXE IDE reset
0xA3 O X O X X X O O DXE IDE detect
0xA4 O X O X X O X X DXE IDE enable
0xA9 O X O X O X X O DXE verifying SETUP password
0xAB O X O X O X O O DXE SETUP start
0xAC O X O X O O X X DXE SETUP input wait
0xAD O X O X O O X O DXE Ready to Boot
0xAE O X O X O O O X DXE Legacy Boot
0xAF O X O X O O O O DXE Exit Boot Services
0xB0 O X O O X X X X RT Set Virtual Address Map Begin
0xB1 O X O O X X X O RT Set Virtual Address Map End
0xB2 O X O O X X O X DXE Legacy Option ROM init
0xB3 O X O O X X O O DXE Reset system
0xB4 O X O O X O X X DXE USB Hot plug
0xB5 O X O O X O X O DXE PCI BUS Hot plug
0xB6 O X O O X O O X DXE NVRAM cleanup
0xB7 O X O O O O O O DXE Configuration Reset
0x00 X X X X X X X X INT19
BIOS Recovery
Progress Code
Diagnostic LED Decoder
O = On, X=Off
Upper Nibble Lower Nibble
MSB 8h 4h 2h 1h 8h 4h 2h 1h LSB
#7 #6 #5 #4 #3 #2 #1 #0
Description

Intel S1200BT Specifications

General

Chipset	Intel C204
Socket	LGA 1155
Form Factor	ATX
Memory Type	DDR3
Max Memory	32 GB
Memory Slots	4
PCIe x16 Slots	1
PCIe x4 Slots	1
PCI Slots	2
SATA Ports	6
Ethernet Ports	2
PCIe x8 Slots	1
Network	Intel 82574L
RAID Support	0, 1, 5, 10
