Intel® Server Board S2600CW Family TPS
Intel® Server Board S2600CW Connector/Header Locations and Pin-outs
Revision 2.4
103
Pin
Signal Name
Pin
Signal Name
62
Key
61
Key
60
Key
59
Key
58
Reserved
57
GND
56
Reserved
55
N/C
54
N/C
53
N/C
52
N/C
51
GND
50
N/C
49
SATA-A+
48
N/C
47
SATA-A-
46
N/C
45
GND
44
N/C
43
SATA-B-
42
N/C
41
SATA-B+
40
N/C
39
GND
38
DEVSLP(1)(0/3.3v)
37
N/C
36
N/C
35
N/C
34
N/C
33
GND
32
N/C
31
N/C
30
N/C
29
N/C
28
N/C
27
GND
26
N/C
25
N/C
24
N/C
23
N/C
22
N/C
21
GND
20
N/C
19
N/C
18
3.3v
17
N/C
16
3.3v
15
GND
14
3.3v
13
N/C
12
3.3v
11
N/C
10
DAS/DSS#(O)(OD)
9
GND
8
N/C
7
N/C
6
N/C
5
N/C
4
3.3v
3
GND
2
3.3v
1
GND
7.4 Management and Security Connectors
7.4.1 RMM4 Lite Connector
A 7-pin Intel
®
RMM4 Lite connector is included on the server board to support the optional
Intel
®
Remote Management Module 4. There is no support for third-party management cards
on this server board.
