Intel® Server Board S2600CW Family TPS Power Supply Specification Guidelines
Revision 2.4
139
From
Length,
mm
To connector
#
No of
pins
Description
Power Supply cover exit hole
500
P5
5
SATA peripheral power connector for 5.25”
Extension from P5
100
P6
5
SATA peripheral power connector for 5.25”
Extension from P6
100
P7
4
Peripheral Power Connector for
5.25”/HSBP Power
Power Supply cover exit hole
600
P8
4
1x4 legacy HSBP Power Connector
Extension from P8
75
P9
4
1x4 legacy HSBP Power Connector
Power supply cover exit hole
700
P10
4
1x4 legacy HSBP Power/Fixed HDD adaptor
Connection
Extension from P10
75
P11
4
1x4 legacy HSBP Power/Fixed HDD adaptor
Connection
Connector only (no cable)
N/a
P12
4
Aux baseboard power connector for PCIe
slots
Connector only (no cable)
N/a
P13
4
GFX card aux connectors
Connector only (no cable)
N/a
P14
4
Connector only (no cable)
N/a
P15
4
Connector only (no cable)
N/a
P16
4
10.3.2.2.1 Baseboard Power Connector (P1)
 Connector housing: 24-pin Molex* Mini-Fit Jr. 39-01-2245 or equivalent
 Contact: Molex* Mini-Fit, HCS Plus, Female, Crimp 44476 or equivalent
Table 64. P1 Baseboard Power Connector
Pin
Signal
18 AWG Color
Pin
Signal
18 AWG Color
1
+3.3VDC
Orange
13
+3.3VDC
Orange
3.3V RS
Orange (24AWG)
2
+3.3VDC
Orange
14
-12VDC
Blue
3
COM
Black
15
COM
Black
4
+5VDC
Red
16
PSON#
Green (24AWG)
5
COM
Black
17
COM
Black
6
+5VDC
Red
18
COM
Black
7
COM
Black
19
COM
Black
8
PWR OK
Gray (24AWG)
20
Reserved
N.C.
9
5 VSB
Purple
21
+5VDC
Red
10
+12V1
Yellow
22
+5VDC
Red
11
+12V1
Yellow
23
+5VDC
Red
12
+3.3VDC
Orange
24
COM
Black
