Intel S2600CW - Appendix D: Platform Specific BMC Appendix

Intel® Server Board S2600CW Family TPS Appendix D: Platform Specific BMC Appendix
Revision 2.4
171
Appendix D: Platform Specific BMC Appendix
This is an addendum document to BMC Core EPS. This document describes platform and
chassis specific information.
Product ID
Bytes 11:12 (product ID) of Get Device ID command response: 71h 00h
IPMI Channel ID Assignments
Below table provides the information of BMC channels’ assignments.
Channel
ID
Interface
Supports
Sessions
0
Primary IPMB
No
1
LAN1
Yes
2
LAN2
Yes
3
LAN3
1
(Provided by the Intel
®
Remote Management Module 4)
Yes
4
Serial
(COM2 terminal mode only)
Yes
5
USB
No
6
SMLink1
(IPMB connection to Node Manager. Bridged through BMC)
No
7
SMM
No
8-0Dh
Reserved
–
0Eh
Self
2
–
0Fh
SMS / Receive Message Queue
No
Notes:
1. Optional HW supported by the server system.
2. Refers to the actual channel used to send the request.
Baseboard Specific Sensors
Sensor Number
Sensor Name
D5h
MEM VRM Temp
D6h
SAS IOC Temp
ACPI S3 Sleep State Support
Not supported.
