2. Intel® Server Board S2600CW Overview
The Intel® Server Board S2600CW is a monolithic printed circuit board (PCB) with features
designed to support the pedestal server markets. This server board is designed to support the
Intel® Xeon® processor E5-2600 v3 and Intel® Xeon® processor E5-2600 v4 product families.
Previous generation Intel® Xeon® processors are not supported.
The Intel® Server Board S2600CW family includes different board configurations:
 Intel® Server Board S2600CW2R: dual 1GbE NIC ports (I350)
 Intel® Server Board S2600CW2SR: dual 1GbE NIC ports (I350) and onboard SAS
controller
 Intel® Server Board S2600CWTR: dual 10GbE NIC ports (X540)
 Intel® Server Board S2600CWTSR: dual 10GbE NIC ports (X540) and onboard SAS
controller
2.1 Intel® Server Board S2600CW Feature Set
Table 1. Intel® Server Board S2600CW Feature Set
Feature
Description
Processors
 Two LGA2011-3 (Socket R3) processor sockets
 Support for one or two Intel® Xeon® E5-2600 v3 or V4 processors product family
 Maximum supported Thermal Design Power (TDP) of up to 145 W
Memory

Eight memory channels (four channels for each processor socket)
 Two DIMM slots for each channel
 Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
 DDR4 Memory data transfer rates: 1333, 1600, 1866, and 2133 MT/s
Chipset
Intel® C612 chipset
Cooling Fan Support

Two processor fans (4-pin headers)
 Six front system fans (6-pin headers)
 One rear system fan (4-pin header)
Add-in Card Slots

Support up to six expansion slots
 From PCH:
- Slot 1: PCIe Gen II x4
 From the first processor:
- Slot 5: PCIe Gen III x16 connector. Electrical x16 for S2600CW2R or
S2600CWTR, electrical x8 for S2600CW2SR or S2600CWTSR
- Slot 6 PCIe Gen III x16 electrical with x16 physical connector
 From the second processor:
- Slot 2: PCIe Gen III x16 electrical with x16 physical connector
- Slot 3: PCIe Gen III x8 electrical with x8 physical connector
- Slot 4: PCIe Gen III x16 electrical with x16 physical connector
