General| Product Type | Server Board |
|---|---|
| Supported Processors | Intel Xeon E5-2600 v3/v4 |
| Supported Memory Types | DDR4 |
| Memory Type | DDR4 |
| RAID Support | RAID 0, 1, 5, 10 |
| Expansion Slots | 1 x PCIe 3.0 x4 (in x8 slot) |
| SATA Ports | 8 |
| M.2 Slots | 1 x M.2 (PCIe 3.0 x4) |
| USB Ports | 4 |
| Power Connectors | 24-pin ATX |
| Management | IPMI 2.0 |
| Form Factor | SSI EEB (12" x 13") |
Details changes and updates made to the technical product specification document.
Legal notices and disclaimers regarding the use and content of the document.
Provides an overview of the document's chapter structure and content.
Important usage disclaimers and responsibilities for system integrators.
Details the key features and specifications of the server board.
Illustrates the physical layout of the server board and component placement.
Information on supported processors, including families and TDP limits.
Details the key features and technologies of the Intel Xeon processors.
Explains the memory controller and subsystem architecture.
Covers the Input/Output features and controllers on the server board.
Details security configuration options available in the BIOS setup utility.
Explains how to set and manage BIOS passwords for system security.
Information on Trusted Platform Module (TPM) hardware security features.
Overview of the integrated BMC firmware's management capabilities.
Details platform management features like power, ACPI, and sensors.
Describes the BMC's sensor monitoring capabilities and types.
Details Intel Intelligent Power Node Manager features and architecture.
Pin-out details for main and CPU power connectors.
Pin-out information for front panel headers and USB connectors.
Details on SATA, SAS, HDD LED, USB, and M.2/NGFF connectors.
Pin-out details for RMM4 Lite, TPM, PMBus, and Chassis Intrusion connectors.
Pin-out information for system and CPU fan connectors.
Pin-out details for serial port and video connectors.
Procedure for resetting BIOS defaults and clearing passwords.
Description and location of the 5-volt stand-by status LED.
Location and function of fan fault indicator LEDs.
Location and function of DIMM fault indicator LEDs.
Overview of system ID, status, and POST code diagnostic LEDs.
Detailed specifications for the 750W redundant power supply.
Specifications for AC input voltage, frequency, and power factor.
Details on over-current, over-voltage, and over-temperature protection.
Specifications for the Higer Power Common Redundant Power Distribution Board.
Operating and non-operating environmental limits for the server board.
Calculated Mean Time Between Failures (MTBF) estimate.
Details POST diagnostic codes related to MRC memory initialization.
