Intel® Server Board S2600CW Family TPS
Intel® Server Board S2600CW Connector/Header Locations and Pin-outs
Revision 2.4
105
7.4.5 IPMB Connector
Table 31. IPMB Connector Pin-out
Pin
Signal Name
1
SMB_IPMB_5VSTBY_DATA
2
GND
3
SMB_IPMB_5VSTBY_CLK
4
P5V_STBY
7.5 FAN Connectors
The server board provides support for nine fans. Seven of them are system cooling fans, and
two of them are CPU fans. The expected maximum RPM is 25000.
7.5.1 System FAN Connectors
The six system cooling fan connectors near the front edge of the board are 6-pin connectors;
the one system cooling fan connector near the edge of the board is a 4-pin connector. The
following table provides the pin-out for all system fan connectors.
Table 32. 6-pin System FAN Connector Pin-out
Pin
Signal Name
1
GND
2
12V
3
TACH
4
PWM
5
PRSNT
6
FAULT
Table 33. 4-pin System FAN Connector Pin-out
Pin
Signal Name
1
GND
2
12V
3
TACH
4
PWM
7.5.2 CPU FAN Connector
The two CPU fan connectors are 4-pin fan connectors. The following table provides the
pin-out for CPU fan connectors.
