Intel® Server Board S2600CW Overview Intel® Server Board S2600CW Family TPS
14 Revision 2.4
2.2.3 Server Board Rear I/O Layout
The following drawing shows the layout of the rear I/O components for the server boards.
Callout
Description
Callout
Description
A
Video
B
USB 2.0
C
Dedicated Management NIC (DMN)
D
USB 3.0
E
NIC1
F
NIC2
G
Diagnostic LEDs
H
ID LED
I
System Status LED
Figure 10. Rear I/O Layout of Intel® Server Board S2600CW
