Intel® Server Board S2600CW Family TPS Power Supply Specification Guidelines
Revision 2.4
Maximum exit air temperature
non-op
Non-operating temperature range
Maximum operating altitude
2
Notes:
1. Under normal conditions, the exit air temperature shall be less than 65°C. 68°C is provided for absolute
worst case conditions and is expected only to exist when the inlet ambient reaches 60°C.
2. T
op_rackped_900
condition only requires maximum altitude of 900m.
The power supply meets UL enclosure requirements for temperature rise limits. All sides of
the power supply, with exception to the air exhaust side, are classified as “Handle, knobs,
grips, and so on”, and held for short periods of time only.
10.2.2 AC Input Requirements
10.2.2.1 Power Factor
The power supply meets the power factor requirements stated in the Energy Star
*
Program
Requirements for Computer Servers. These requirements are stated below.
Table 44. Power Factor Requirements for Computer Servers
Tested at 230VAC, 50Hz and 60Hz and 115VAC, 60Hz
Tested according to Generalized Internal Power Supply Efficiency Testing Protocol Rev 6.4.3. This is posted at
http://efficientpowersupplies.epri.com/methods.asp.
10.2.2.2 AC Inlet Connector
The AC input connector is an IEC 320 C-14 power inlet. This inlet is rated for 10A/250VAC.
10.2.2.3 AC Input Voltage Specification
The power supply operates within all specified limits over the following input voltage range.
Harmonic distortion of up to 10% of the rated line voltage does not cause the power supply to
go out of specified limits. Application of an input voltage below 85VAC does not cause
damage to the power supply, including a blown fuse.
Table 45. AC Input Voltage Range
rms
rms
rms
rms
rms
rms
Notes:
1. Maximum input current at low input voltage range shall be measured at 90VAC, at maximum load.
2. Maximum input current at high input voltage range shall be measured at 180VAC, at maximum load.
3. This requirement is not to be used for determining agency input current markings.
