Intel® Server Board S2600CW Connector/Header Locations and Pin-outs
Intel® Server Board S2600CW Family TPS
106 Revision 2.4
Table 34. CPU FAN Connector Pin-out
Pin
Signal Name
1
GND
2
12V
3
TACH
4
PWM
7.6 Serial Port and Video Connectors
7.6.1 Serial Port Connector
The server board includes one internal DH-10 serial port connector.
Table 35. Serial Port B Connector Pin-out
Pin
Signal Name
Pin
Signal Name
1
SPA_DCD
2
SPA_DSR
3
SPA_SIN
4
SPA_RTS
5
SPA_SOUT_N
6
SPA_CTS
7
SPA_DTR
8
SPA_RI
9
GND
7.6.2 Video Connector
The following table details the pin-out definition of the external VGA connector.
Table 36. Video Connector Pin-out
Pin
Signal Name
1
CRT_RED
2
CRT_GREEN
3
CRT_BLUE
4
N/C
5
GND
6
GND
7
GND
8
GND
9
P5V
10
GND
11
NC
12
CRT_DDCDATA
13
CRT_HSYNC
14
CRT_VSYNC
15
CRT_DDCCLK
