Intel® Server Board S2600CW Family TPS Intel® Server Board S2600CW Functional Architecture
Revision 2.4
49
3.4.12.2 Setting Video Configuration Options using the BIOS Setup Utility
Advanced
PCI Configuration
Memory Mapped I/O above 4 GB
Enabled / Disabled
Memory Mapped I/O Size
Auto/1G/2G/4G/8G/16G/32G/64G/128G/256G/512G/
1024G
Add-in Video Adapter
Enabled / Disabled
Onboard Video
Enabled / Disabled
Legacy VGA Socket
CPU Socket 1 / CPU Socket 2
PCIe Slot Bifurcation Setting
NIC Configuration
UEFI Network Stack
UEFI Option ROM Control
PCIe Port Oprom Control
Figure 16. BIOS Setup Utility Video Configuration Options
1. Add-in Video Adapter
Option Values: Enabled
Disabled
Help Text:
If enabled, the Add-in video adapter works as primary video device during POST
if installed. If disabled, the on-board video controller becomes the primary video
device.
Comments: This option must be enabled to use an add-in card as a primary POST
Legacy Video device.
If there is no add-in video card in any PCIe slot connected to CPU Socket 1 with the
Legacy VGA Socket option set to CPU Socket 1, this option is set to Disabled and
grayed out and unavailable.
If there is no add-in video card in any PCIe slot connected to CPU Socket 2 with the
Legacy VGA Socket option set to CPU Socket 2, this option is set to Disabled and
grayed out and unavailable.
If the Legacy VGA Socket option is set to CPU Socket 1 with both Add-in Video Adapter
and Onboard Video Enabled, the onboard video device works as primary video device
while add-in video adapter as secondary.
