Intel® Server Board S2600CW Functional Architecture Intel® Server Board S2600CW Family TPS
48 Revision 2.4
Case 4: Both onboard video and add-in video are active displays. But only onboard
could be the active display during BIOS POST (Dual Monitor).
Onboard Video = Enabled
Legacy VGA Socket = CPU Socket 1 (grayout, can't change)
Add-in Video Adapter = Enabled
When there is one add-in video card connected to CPU Socket 2...
Case 5: Onboard video active display, add-in doesn't display.
Onboard Video = Enabled
Legacy VGA Socket = CPU Socket 1
Add-in Video Adapter = Disabled (grayout, can't change)
Case 6: Add-in video active display, onboard video doesn't display.
Onboard Video = Disabled (grayout, can't change)
Legacy VGA Socket = CPU Socket 2
Add-in Video Adapter = Enabled (grayout, can't change)
When there are add-in video cards connected to both CPU Socket 1 & 2...
Case 7: Onboard video active display, add-in video on Socket 1 and Add-in video on
Socket 2 don’t actively display.
Onboard Video = Enabled
Legacy VGA Socket = CPU Socket 1
Add-in Video Adapter = Disabled
Case 8: Add-in video on Socket 1 active display, onboard video and Add-in video on
Socket 2 don’t actively display.
Onboard Video = Disabled
Legacy VGA Socket = CPU Socket 1
Add-in Video Adapter = Enabled
Case 9: Both onboard video active and CPU Socket 1 add-in video active display. But
only onboard could actively display during BIOS POST.
Onboard Video = Enabled
Legacy VGA Socket = CPU Socket 1
Add-in Video Adapter = Enabled
Case 10: Only CPU Socket 2 add-in video active display, neither onboard video nor
CPU Socket 1 add-in video display.
Onboard Video = Disabled (grayout, can't change)
Legacy VGA Socket = CPU Socket 2
Add-in Video Adapte = Enabled (grayout, can't change)
