Intel® Server Board S2600CW Overview Intel® Server Board S2600CW Family TPS
4 Revision 2.4
Feature
Description
RAID Support

PCH SATA 6G
- ESRT2 RAID 0/1/10
- Optional RAID 5 is supported through the ESRT2 RAID5 upgrade key
 LSI* SAS3008 SAS 12G
- Integrated RAID 0/1/1E/10
- Integrated MegaRaid 0/1/10/5/50 upgrade is supported through the
upgrade key AXXRPFKHY5
External back panel I/O
Connectors

One DB-15 video connector
 Two NIC ports (I350 for 1GbE or X540 for 10GbE)
 One NIC port dedicated to server management (DMN)
 Two USB 3.0 ports and two USB 2.0 ports
Internal I/O
Connectors/Headers

Two 7-pin SATA 6G ports
 Two mini-SAS HD connectors supporting eight SATA 6Gbps transfer rate
 Two mini-SAS HD connectors supporting eight SAS 12Gbps transfer rate
(S2600CW2SR and S2600CWTSR only)
 One 2x10-pin connector providing front panel support for two USB 3.0 ports
 One internal Type-A USB 2.0 port
 One internal USB port to support low profile eUSB SSD
 One DH-10 Serial Port B connector
 One 24-pin SSI-EEB compliant front panel header
 One TPM connector
 One M.2/NGFF connector
 One RMM4 LITE connector
Video Support

Integrated 2D Video Controller
 16 MB DDR3 Memory
Server Management

Support for Intel® Remote Management Module 4 solutions
 Intel® Light-Guided Diagnostics on field replaceable units
 Support for Intel® System Management Software
 Support for Intel® Intelligent Power Node Manager (PMBus*-compliant power
supply needed)
Security
Intel® TPM – AXXTPME5 (Accessory Option)
Form Factor
SSI EEB (12”x13”)
Compatible Intel
®
Server
Chassis
Intel® Server Chassis P4304XXMFEN2 and P4304XXMUXX
