Appendix D: Platform Specific BMC Appendix Intel® Server Board S2600CW Family TPS
Revision 2.4
172
Processor Support for Intel
®
Server Board S2600CW
 Intel® Xeon® E5-2600 v3 and v4 up to 145 Watt
Supported Chassis
 Intel® Server Chassis P4304XXMFEN2
 Intel® Server Chassis P4304XXMUXX
Chassis-specific Sensors
Fan Tachometer Sensors:
Intel® Server Chassis
Fan Tachometer Sensors
(Sensor Number)
Fan Presence Sensors
(Sensor Number)
P4304XXMFEN2
System Fan 1 (30h)
NA
System Fan 2 (31h)
NA
P4304XXMUXX
System Fan 1 (30h)
Fan 1 Present (40h)
System Fan 2 (31h)
Fan 2 Present (41h)
System Fan 3 (32h)
Fan 3 Present (42h)
System Fan 4 (33h)
Fan 4 Present (43h)
System Fan 5 (34h)
Fan 5 Present (44h)
Hot-plug Fan Support
Supported on Intel® Server Chassis P4000 Redundant (Union Peak Medium) only
Fan Redundancy Support
Supported on Intel® Server Chassis P4000 Redundant (Union Peak Medium) only
Fan Domain Definition
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
P4304XXMUXX 0
DIMM Thrm Mrgn 1 (B0h)
DIMM Thrm Mrgn 2 (B1h)
DIMM Thrm Mrgn 3 (B2h)
DIMM Thrm Mrgn 4 (B3h)
LAN/BMC Temp (23h)
HSBP 1 Temp (29h)
SSB Temp (22h)
LAN NIC Temp (2Fh)
Exit Air Temp (2Eh)
P1 DTS Therm Mgn (83h)
System Fan 1 (30h)
