Appendix D: Platform Specific BMC Appendix Intel® Server Board S2600CW Family TPS
Revision 2.4
174
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
Exit Air Temp (2Eh)
P1 DTS Therm Mgn (83h)
P2 DTS Therm Mgn (84h)
MIC 1 Margin (C4h)
MIC 2 Margin (C5h)
MIC 3 Margin (C6h)
4
DIMM Thrm Mrgn 1 (B0h)
DIMM Thrm Mrgn 2 (B1h)
DIMM Thrm Mrgn 3 (B2h)
DIMM Thrm Mrgn 4 (B3h)
SAS IOC Temp (D6h)
MEM EFVRD Temp (24h)
MEM VRM Temp (D5h)
P1 VRD Temp (25h)
HSBP 1 Temp (29h)
Exit Air Temp (2Eh)
P1 DTS Therm Mgn (83h)
P2 DTS Therm Mgn (84h)
MIC 1 Margin (C4h)
MIC 2 Margin (C5h)
MIC 3 Margin (C6h)
System Fan 5 (34h)
5
PS1 Temperature (5Ch)
PS2 Temperature (5Dh)
Power supply fans
P4304XXMFEN2
0
DIMM Thrm Mrgn 1 (B0h)
DIMM Thrm Mrgn 2 (B1h)
DIMM Thrm Mrgn 3 (B2h)
DIMM Thrm Mrgn 4 (B3h)
LAN/BMC Temp (23h)
HSBP 1 Temp (29h)
SSB Temp (22h)
LAN NIC Temp (2Fh)
Exit Air Temp (2Eh)
P1 DTS Therm Mgn (83h)
P2 DTS Therm Mgn (84h)
System Fan 1 (30h)
1
DIMM Thrm Mrgn 1 (B0h)
DIMM Thrm Mrgn 2 (B1h)
DIMM Thrm Mrgn 3 (B2h)
DIMM Thrm Mrgn 4 (B3h)
SAS IOC Temp (D6h)
MEM EFVRD Temp (24h)
MEM VRM Temp (D5h)
P1 VRD Temp (25h)
System Fan 2 (31h)
