Appendix E: POST Code Diagnostic LED Decoder Intel® Server Board S2600CW Family TPS
Revision 2.4
178
0xAC
Phy layer settings
0xAD
Link Layer settings
0xAE
Coherency settings
0xAF
QPI initialization done
0x07
Early SB initialization during SEC phase
0x08
Early NB initialization during SEC phase
0x09
End of SEC phase
0x0E
Microcode Not Found
0x0F
Microcode Not Loaded
PEI Phase
0x10
PEI Core
0x11
CPU PEIM
0x15
NB PEIM
0x19
SB PEIM
MRC Progress Codes
At this point the MRC Progress Code sequence ix executed.
See Table 94.
0x31
Memory Installed
0x32
CPU PEIM (CPU Init)
0x33
CPU PEIM (Cache Init)
0x4F
DEX IPL Started
DXE Phase
0x60
DXE Core started
0x61
DXE NVRAM Init

Intel S2600CW Specifications

General

Product Type	Server Board
Supported Processors	Intel Xeon E5-2600 v3/v4
Supported Memory Types	DDR4
Memory Type	DDR4
RAID Support	RAID 0, 1, 5, 10
Expansion Slots	1 x PCIe 3.0 x4 (in x8 slot)
SATA Ports	8
M.2 Slots	1 x M.2 (PCIe 3.0 x4)
USB Ports	4
Power Connectors	24-pin ATX
Management	IPMI 2.0
Form Factor	SSI EEB (12" x 13")
