Intel S7200AP - HNS7200 AP Compute Module Feature Set; Table 2. Intel Compute Module HNS7200 AP Product Family Feature Set

Feature
Description
Riser Support

One PCIe Gen3 x16 standard riser connector
o Supports a low-profile adapter in Riser Slot 1
 One PCIe Gen3 x20 HSEC-8 fine-pitch riser connector
o Supports a x16 low-profile adapter in Riser Slot 2
o Supports a x4 low-profile adapter in Riser Slot 2 when CPUs with
integrated Intel® Omni-Path Fabric are used
On-board storage
controllers and options

Integrated 10-port SATA
o 5 ports to bridge board,
o 1 port to mSATA
o 4 ports to MiniSAS HD connector
Fabric

Dual port Intel® Omni-Path Fabric via
Xeon™ Phi™ x200 Product Family
or

Single Port Intel® Omni-Path Fabric via x16 Gen 3 PCIe Adapter
Network (LAN)

Dual i210 Springvilles
 Dual 10/100/1000Gbe RJ45 connectors
 NC_SI sideband to BMC. Option to host share or dedicate a Network port
to management traffic.
Server Management
 Onboard Emulex* Pilot III* Controller
 Support for Intel
®
Remote Management Module 4 Lite solutions
 Support for Intel
®
System Management Software
 Support for Intel
®
Intelligent Power Node Manager
NOTE: The Riser Slot 1 on the server board is designed for plugging in ONLY the riser adapter. Plugging
in a PCIe* adapter directly into the riser slot may cause permanent server board and/or PCIe* card
damage.
1.1.2 HNS7200AP Compute Module Feature Set
Table 2. Intel® Compute Module HNS7200AP Product Family Feature Set
Feature
1
Description
Server Board
Intel® Xeon™ Phi™ x200 Product Family
 Single processor socket P (3647 pins)
 Thermal Design Power (TDP) up to 230W
 36 lanes of Integrated PCI Express® 3.0 low-latency I/O

CPUs with Integrated Intel® Omni-Path Fabric supported
Processor TDP Support
Maximum supported Thermal Design Power (TDP) of up to 230W
Heatsink

One 80x107mm 1U Heatsink
Fan
Three 40x56mm dual rotor system fans
Riser Support

One PCIe Gen3 x16 standard riser connector
o Supports a low-profile adapter in Riser Slot 1
 One PCIe Gen3 x20 HSEC-8 fine-pitch riser connector
o Supports a x16 low-profile adapter in Riser Slot 2
o Supports a x4 low-profile adapter in Riser Slot 2 when CPUs
with integrated Intel® Omni-Path Fabric are used
Compute Module Board
 Bridge boards:
o 6G SATA Bridge Board (Default)

One compute module power docking board
Air Duct
One transparent air duct
