Length 14.17” (360m), width 6.81” (173mm)
NOTE: The table only lists features that are unique to the compute module or different with the server
board.
1. ONLY standard low profile PCIe* cards can be installed in the riser card slots.
1.1.3 Chassis Feature Set for Intel® Compute Module HNS7200AP
The following table lists a brief description of the 2U H2000G Chassis Product Family features,
438mm x 86.9mm x 771/733mm
17.24” width x 3.42 length x 30.35/28.86” height
Intel® Compute Module options:
HNS7200AP (up to four)
3 dual rotor 40 x 56 mm fixed fans per node
Two low profile PCIe cards on riser 1 and 2
8 x 2.5” SATA drive Note: 2.5” SATA HDD installed in the 3.5” Drive Carrier
16 x 2.5” SATA drives
Bridge Board Options:
(1) 6G SATA only RAID 0, 1, 10 SW RAID ESRT2
Support for H2312XXLR2 and H2216XXLR2 chassis only
Note: Intel® Compute Module HNS7200AP is not supported in Intel® Server Chassis H2204XXLRE
For additional details on chassis features, refer to the Intel® Server Chassis H2000G and H2000P Product
Family TPS and Service Guide.
Table 3. Intel® Server Board S7200APR (Refresh) Product Family Feature Set
