Table 11. MRC Progress Codes
Progress Code
Main Sequence
Subsequences/Subfunctions
0xB0 Detect DIMM population
—n/a—
0xB1 Set DDR4 frequency
—n/a—
0xB2 Gather remaining SPD data
—n/a—
0xB3 Program registers on the memory controller level
—n/a—
0xB4 Evaluate RAS modes and save rank information
—n/a—
0xB5 Program registers on the channel level
—n/a—
0xB6 Perform
the JEDEC defined initialization
sequence
—n/a—
0xB7 Train DDR4 ranks
—n/a—
0x01

Read DQ/DQS training
0x02

Receive Enable training
0x03

Write Leveling training
0x04

Write DQ/DQS training
0x05

DDR channel training done
0xB8 Initialize CLTT/OLTT
—n/a—
0xB9 Hardware memory test and init
—n/a—
0xBA Execute software memory init
—n/a—
0xBB Program memory map and interleaving
—n/a—
0xBC Program RAS configuration
—n/a—
0xBF MRC is done
