2.9.2 Removing a PCIe* Add-In Card from Riser 2
1. Power off the compute module and disconnect the power cable(s).
2. Remove the air duct. See section 2.3.1
.
3. Loosen the three screws (See letter A).
4. Pull straight up on Riser 2 with the PCIe* Add-In Card assembly (See letter B).
Figure 63. Removing the PCIe* Add-In Card – Step 1
5. Lift out the PCIe* Slot 2 Riser with Add-In-Card.
