Intel S7200AP - HNS7200 APR Compute Module Feature Set; Table 4. Intel Compute Module HNS7200 APR Product Family Feature Set

Feature
Description
Network (LAN)

Dual i210 Springvilles
 Dual 10/100/1000Gbe RJ45 connectors
 NC_SI sideband to BMC. Option to host share or dedicate a Network port
to management traffic.
RAID Support
 Intel
®
Embedded Server RAID Technology 2 (ESRT2)
Server Management

Onboard Emulex* Pilot III* Controller
 Support for Intel
®
Remote Management Module 4 Lite solutions
 Support for Intel
®
System Management Software

Support for Intel
®
Intelligent Power Node Manager
NOTE: The Riser Slot 1 on the server board is designed for plugging in ONLY the riser adapter. Plugging
in a PCIe* adapter directly into the riser slot may cause permanent server board and/or PCIe* card
damage.
1.1.4 HNS7200APR Compute Module Feature Set
Table 4. Intel® Compute Module HNS7200APR Product Family Feature Set
Feature
1
Description
Server Board
Intel® Xeon™ Phi™ 72x5 Product Family
 Single processor socket P
 Thermal Design Power (TDP) up to 320W with the 1U LACC
thermal solution
 36 lanes of Integrated PCI Express® 3.0 low-latency I/O
Intel® Xeon™ Phi™ x200 Product Family
 Single processor socket P (3647 pins)
 Thermal Design Power (TDP) up to 230W (Air Cooled Heatsink)
 36 lanes of Integrated PCI Express® 3.0 low-latency I/O

CPUs with Integrated Intel® Omni-Path Fabric supported
Processor TDP Support
Maximum supported Thermal Design Power (TDP) of up to 320W
Heatsink
 One 80x107mm 1U Heatsink-CPUs < 245W TDP
Liquid Assisted Air Cooling (LAAC)
 1U Liquid Assisted Air Cooling (LAAC) -CPUs > 245W TDP
Fan
Three 40x56mm dual rotor system fans
Riser Support

One PCIe Gen3 x16 standard riser connector
o Supports a low-profile adapter in Riser Slot 1
 One PCIe Gen3 x20 HSEC-8 fine-pitch riser connector
o Supports a x16 low-profile adapter in Riser Slot 2
o Supports a x4 low-profile adapter in Riser Slot 2 when CPUs
with integrated Intel® Omni-Path Fabric are used
Compute Module Board
 Bridge boards:
o 6G SATA Bridge Board (Default)

One compute module power docking board
Air Duct
One transparent air duct
Form Factor
Length 14.17” (360m), width 6.81” (173mm)
NOTE: The table only lists features that are unique to the compute module or different with the server
board.
1. ONLY standard low profile PCIe* cards can be installed in the riser card slots.
