Feature
Description
Processor Support
Intel® Xeon™ Phi™ 72x5 Product Family
 Single processor socket P
 Thermal Design Power (TDP) up to 320W with the 1U LACC thermal
solution
 36 lanes of Integrated PCI Express® 3.0 low-latency I/O
Intel® Xeon™ Phi™ x200 Product Family
 Single processor socket P (3647 pins)
 Thermal Design Power (TDP) up to 230W (Air Cooled Heatsink)
 36 lanes of Integrated PCI Express® 3.0 low-latency I/O

CPUs with Integrated Intel® Omni-Path Fabric supported
Memory Support

Six DIMM slots in total across six memory channels
 Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
 Memory DDR4 data transfer rates of 2400/2666 MT/s
 1 DIMM per channel

Max memory 384GB
Chipset
Intel C610 “Wellsburg” Platform Controller Hub (PCH)
External I/O Connections

Two USB 3.0 connectors

Two RJ-45 10/100/1000 Mbit Network Interface Controller (NIC) ports
Internal I/O
connectors/headers

One USB 2.0 Header
 One TPM Header
 One Intel® Omni-Path Fabric Signal Connector
 One mSATA Connector
 One Bridge Board Connector
 One 2x7 pin header for system fan module
 One Aux Front Panel Connector
 Three 8 pin fan headers for third-party chassis support
 One 4 pin CPU fan or liquid cooling pump support header
 One PSU Control Header
 One RMII header for Intel® RMM4 Lite
 One internal RGB Video Header

One Serial Port A Header
PCIe Support
PCIe* 3.0 (2.5, 5, 8 GT/s)
Power Connections
• One 2x4 pin main power connector
• One 2x2 pin aux. power connector
•
One 4 pin power connector for disk drive power
System Fan Support

Three 40x56mm double rotor fans

One 4 pin CPU fan or liquid cooling pump support header
Video
 Integrated 2D video graphics controller

128MB DDR3 memory
Riser Support

One PCIe Gen3 x16 standard riser connector
o Supports a low-profile adapter in Riser Slot 1
 One PCIe Gen3 x20 HSEC-8 fine-pitch riser connector
o Supports a x16 low-profile adapter in Riser Slot 2
o Supports a x4 low-profile adapter in Riser Slot 2 when CPUs with
integrated Intel® Omni-Path Fabric are used
On-board storage
controllers and options
 Integrated 10-port SATA
o 5 ports to bridge board,
o 1 port to mSATA
o 4 ports to MiniSAS HD connector
Fabric
 Single Port Intel® Omni-Path Fabric via x16 Gen 3 PCIe Adapter
