Installing BDU
31
6.3 BDU Mounting Template
The BDU mounting holes must be in the exact same place as shown in the provided mounting template
below.
Drill Hole
Ф 3.8 mm (0.14")
diameter in
4 positions
300 mm (11.81")
126.8 mm (4.99")
Figure 18: BDU Mounting Template
