Operating BDU
51
7.6 Using Grandstream VoIP Phone Call
Use the Grandstream VoIP phone to make VoIP phone calls.
Recommended VoIP Phones
• Grandstream GXP16 Series: 1610, 1615, 1620, 1625, 1628, 1630
• Grandstream GXP17 Series: 1760, 1780
• Grandstream GXP21 Series: 2120, 2130, 2135, 2140, 2160, 2170
• Grandstream GXV32 Series: 3240, 3275
1. Connect an Ethernet Cable from a LAN port (Port 1~ Port 4) on the back of the BDU to a LAN port of
devices. Only the LAN Port 1 and LAN Port 2 of BDU are Power over Ethernet (PoE) capable.
2. On the front LCD panel of the phone, go to Menu > Status > Network Status. Note the IP address for
IPv4 accessing the web interface of the VoIP phone.
For example, IP address 192.168.0.132 is displayed on the LCD panel.
3. On your laptop, open a web browser and type in the IP address for IPv4 (http://192.168.0.132). Log into
the web interface of the VoIP phone using the user name and password.
• Login Username: admin
• Password: admin
To Next Page
