Intellian FB250 Installation & Operation User Guide

Planning Installation
17
4.2.3 Packing List
Before beginning installation, make sure you have all the included components.
The ADU Package & BDU Package are provided in one box.
NOTE: The USIM card is provided by the service provider and may be packaged separately.
Above Deck Unit (ADU) Package for FB250
Item Q'ty Size Description
Above Deck Unit (ADU) 1 Antenna Unit
Antenna RF Cable
(LMR200, TNC/M-TNC/M Type)
1 25 m To Connect ADU - BDU
Antenna Mounting Template 1 Antenna Mounting Template
Hex Bolt 5 M6 x 30 L
To Mount Antenna on Mounting Surface (M6 Bolt
Kit)
Spring Washer 5 M6
Flat Washer 5 M6
Above Deck Unit (ADU) Package for Fleet One
Item Q'ty Size Description
Above Deck Unit (ADU) 1 Antenna Unit
Antenna RF Cable
(LMR200, TNC/M-TNC/M Type)
1 10 m To Connect ADU - BDU
Antenna Mounting Template 1 Antenna Mounting Template
Hex Bolt 5 M6 x 30 L
To Mount Antenna on Mounting Surface
(M6 Bolt Kit)
Spring Washer 5 M6
Flat Washer 5 M6
Below Deck Unit (BDU) Package
Item Q'ty Size Description
Below Deck Unit (BDU) 1
315 mm x 190 mm x
42 mm
Below Deck Unit
DC Power Cable 1 1 m BDU Power
Ethernet Cable (RJ45 / LAN) 1 1 m To Connect BDU to PC
Wi-Fi Antenna 1
Quick Installation Guide (QIG) 1 Quick Installation Guide
Tapping Screw 5 M5 x 16 L To Fix BDU (Direct Mounting Type)
Terminal Block 1
85 mm x 40 mm x
36 mm
For Inter-connection of Cables
