FB250/Fleet One - Marine Satellite Communication System
20
4.4 Unpacking System Package
Follow the steps for easy and safe unpacking. The system package consists of two sub-packages that an ADU Package
and a BDU Package.
520 (20.47)
520 (20.47)
505 (19.88)
505 (19.88)
505 (19.88)
360 (14.17)
ADU Package
505 (19.88)
505 (19.88)
115 (4.52)
BDU Package
Unit: mm (inch)
Figure 5: Unpacking System Package (with ADU & BDU Sub-package)
1. Remove the top cover and take out the BDU package including a Quick Installation Guide, a BDU Unit, a
Wi-Fi Antenna, a DC Power Cable, an Ethernet Cable, a BDU Bolt Kit, and a Terminal Block. The 19-inch
Rack Mount Kit (Optional) can be purchased separately.
Rack Mount Bolt Kit
19-inch Rack
Mount Kit (Optional)
AC Power Cord
AD-DC Adaptor
Rackmount Plate
Cable Tray
BDU Unit
Quick Installation
Guide (QIG)
BDU Bolt Kit
Ethernet Cable
DC Power Cable
Terminal Block
Wi-Fi Antenna
Figure 6: Unpacking BDU Package
