Using AptusLX
97
8.9.5 Diagnostic
1
2
3
4
5
No. Item Description
①
Diagnostic Executes antenna diagnosis test to check the antenna status.
②
Hardware Test
Mode Status
Sets the hardware test function by toggling the activation button (Active/
Inactive).
③
Self Test
The activation button must be selected to the "Active" in the previous step.
Click the Start button to run the self-test.
④
Self Test Results Displays the self-test result.
⑤
ADU Diagnostic
Executes the ADU diagnosis test to check each part of ADU status.
Select the ADU part to test by toggling the activation button (Enabled/Disable).
Click the Start button to run the test.
WARNING
While selecting the Active button in the Hardware Test Mode Activate menu, the system is in the hardware
test mode. Select the Inactive button for normal operation.
To Next Page
