INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine RS485 communication LCD keypad
-131-
03.17 16:02:35
Home
Motor type AM
Return Edit
Master param setting
Max frequency 050.00 Mpa
Rated power 0090.0 kW
Rated frequency 050.00 Hz
Rated voltage 000380 V
Rated current 0176.0 A
03.17 16:02:35
Home
Param auto-tuning
Return Edit
Master param setting
Rotor resistor 00.025 Ω
Leakage inductance 00.006 mH
Mutual inductance 00.169 mH
No-load current 0040.8 A
Stator resistor 00.030 Ω
Figure B-50 Master parameter setting interface
Step 2 Enter the system parameter setting interface.
According to the sensor configuration, set the pressure sensor parameters, temperature sensor
parameters, and oriented function parameters. Then return to the system configuration interface.
03.17 16:02:35
Home
Max voltage limit xxxx.x %
Return Edit
System param setting
Uplimit freq press drop xxx.xx MPa
Temp sensor channel PT1
Power correct coeffi xxxxxx %
Uplimit freq drop rate xxx.xx Hz
Press sensor P1 uplimit xxx.xx MPa
Home
Press sensor P2 Uplimit xxx.xx MPa
Return Edit
Maintain Timeout xxxxxx h
Press sensor channel P1
Figure B-51 System parameter setting interface
