INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Commissioning instruction
-24-
Function
code
Name
Parameter setting
Remarks
P00.05
Lower limit of
running frequency
Model depended
0.00Hz–P00.04 (upper limit
of running frequency)
P00.14
Carrier frequency
setting
Model depended
4KHz (default value)
P00.18
Function parameter
restore
1
1: Restore to default value
4. Set the motor parameters according to the nameplate.
Table 4-2 Motor parameter configuration
Function
code
Name
Parameter
setting
Remarks
P00.15
Motor parameter
autotuning
1, 2
1: Rotary autotuning
2: Static autotuning 1 (comprehensive
autotuning)
P02.00
Motor type
1
Motor type: synchronous motor (SM)
P02.15
Rated power of SM 1
Model
depended
0.1–3000.0kW
P02.16
Rated frequency of
SM 1
Model
depended
0.01Hz–P00.03 (max. output
frequency)
P02.17
Number of pole pairs
of SM 1
Model
depended
1–50
P02.18
Rated voltage of SM 1
Model
depended
0–1200V
P02.19
Rated current of SM 1
Model
depended
0.8–6000.0A
P02.23
Counter-emf constant
of SM 1
Model
depended
0–10000
Note:
 It’s a must to perform motor parameter autotuning after motor parameters are set completely.
 If the motor is already loaded on the site, it is recommended to perform static autotuning 1
(comprehensive autotuning).
 Start jogging after parameters are identified.
5. Configure parameters with one click
Start/stop the VFD with one click in communication mode when P00.18=3. The details of parameter
configuration are shown in Table 4-3.
