INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Commissioning instruction
-25-
Table 4-3 Parameters for starting/stopping the main motor through communication
Function
code
Name
Parameter
setting
Remarks
P00.01
Channel of running
commands
2
2: Communication (LED on)
P00.06
Setting channel of A
frequency command
8
8: Modbus communication
P00.11
ACC time 1
20
0.0–3600.0s
P00.12
DEC time 1
20
0.0–3600.0s
P00.18
Function parameter
restore
3
3: Start/stop the VFD with one click in
communication mode
4: Start/stop the VFD with one click in
terminal mode
P05.01
Function of S1
0
No function
P05.02
Function of S2
48
48: Fan running control signal
P05.03
Function of S3
49
49: Solenoid valve control signal
P06.01
Y1 output
5
5: VFD in fault
P06.03
Solenoid valve
output
28
28: Solenoid valve control output
P14.00
Local communication
address
1
1–247; 0 indicates a broadcast address
P14.01
Communication baud
rate
3
3: 9600BPS
P14.02
Data bit check
0
0: No parity check (N, 8, 1) for RTU
P14.04
Communication
timeout time
40.0
0.0 (invalid); 0.1–60.0s
P14.05
Transmission error
processing
4
4: Alarm and coast to stop, and automatic
fault reset after communication is
restored
P18.43
Fan control mode
1
1: Terminal, the power-frequency fan
starts/stops via terminals
P21.00
Rated current of the
fan
Modifiable
7.5 kW/11 kW/15kW, fan 0.75kW 2.5A
22kW, fan 1kW 3A
30kW/37kW, fan 1.5kW 3.7A
Note:
 The size of the rated fan current will be selected automatically according to the power stage of
the VFD.
 Fan parameters can be changed according to actual conditions.
