INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-42-
Function
code
Name
Description
Default
Modify
43: Oil filter blockage signal
44: Separator blockage signal
45: Precision splitter blockage signal
46: External fault 1 (motor overtemperature)
47: External fault 2
48: Fan running control signal (valid when
P18.43=1)
49: Solenoid valve control signal
50: Cooling fan control signal of main motor
51: PTC signal (valid when P18.00=1)
52–63: Reserved
P05.10
Input terminal polarity
The function code is used to set the polarity
of input terminals.
When a bit is 0, the input terminal is positive;
when a bit is 1, the input terminal is negative.
BIT8
BIT7
BIT6
BIT5
Reserv
ed
Reserv
ed
Reserv
ed
Reserv
ed
BIT4
BIT3
BIT2
BIT1
BIT0
Reserv
ed
PTC
S3
S2
S1
Setting range: 0x000–0x1FF
0x008
○
P05.11
Digital input filter
time
0.000–1.000s
0.200s
○
P05.12
Virtual terminal setting
0: Virtual terminals are invalid
1: Modbus communication virtual terminals
are valid
2–4: Reserved
0
◎
P05.13
Terminal control mode
0: 2-wire control 1
1: 2-wire control 2
2: 3-wire control 1
3: 3-wire control 2
0
◎
P05.14
S1 switch-on delay
0.000–50.000s
0.000s
○
P05.15
S1 switch-off delay
0.000s
○
P05.16
S2 switch-on delay
0.000s
○
P05.17
S2 switch-off delay
0.000s
○
P05.18
S3 switch-on delay
0.000s
○
P05.19
S3 switch-off delay
0.000s
○
