INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-53-
Function
code
Name
Description
Default
Modify
1: Enable
P08.28
Auto fault reset count
During the automatic reset period, the fault
will not be reported externally, only the
keypad TRIP indicator blinks, and P17.39
shows the warning code. The automatic fault
reset function is enabled for these faults,
such as OUt1, OUt2, Out3, OL1, OL2, OH1,
OH2, EF, CE, ItE, tE, EEP, END, PCE, UPE,
DNE, ETH1, ETH2, PSF, etc. Fault codes
will be reported immediately when these
types of faults occur.
Setting range of P08.28: 0–10
Setting range of P08.29: 0.1–3600.0s
5
○
P08.29
Auto fault reset interval
setting
5.0s
○
P08.30
Frequency decrease
ratio in drop control
0.00–50.00Hz
0.00Hz
○
P08.32
FDT1 electrical level
detection value
0.00–P00.03 (max. output frequency)
50.00Hz
○
P08.33
FDT1 lagging detection
value
-100.0–100.0% (FDT1 electrical level)
5.0%
○
P08.34
FDT2 electrical level
detection value
0.00–P00.03 (max. output frequency)
50.00Hz
○
P08.35
FDT2 lagging detection
value
-100.0–100.0% (FDT2 electrical level)
5.0%
○
P08.36
Detection value for
frequency being
reached
0.0–P00.03 (max. output frequency)
0.00Hz
○
P08.39
Running mode of
cooling fan
0: Common running mode: Do not run during
sleep.
1: The fan keeps running after power-on
2: Temperature control: The fan turns on
when IGBT temperature is higher than 50℃
and turns off when it is lower than 45℃.
0
○
P08.40
PWM selection
0x00–0x21
LED ones: PWM mode selection
0: PWM mode 1, 3PH modulation and 2PH
modulation
1: PWM mode 2, 3PH modulation
01
◎
