6-12
Capter 6 Adjust Mode
6.6.4 Label feed
Menu name Specification
SENSOR TYPE Select the sensor type.
0: NONE / 1: LABEL / 2: MARK
PRINT SPEED Select the print speed.
100 mm/s / 120 mm/s / 150 mm/s
BACK FEED Select whether or not to set the back feed.
NO / YES
LABEL SENS. DIS. Enter the label sensor distance.
Input range: 0 to 99.9
PRE-PRINT
LENGTH
Enter the pre-print length.
Input range: 0 to 99.9
LABEL GAP
DETECT.
Enter the label sensor threshold.
Input range: 0 to 255
SENSITIVITY Enter the label sensor sensitivity.
Input range: 0 to 255
LABEL SENSOR
LEVEL
Display the output value of label sensor.
DETAIL Transfer to the label sensor details screen.
To Next Page
