ISHIDA UNI-8 - Load Cell

3-14
Capter 3 Machihe disassembly
3.3.10 Load Cell
1. Remove the three screws.
2. Remove the two screws and
detach the load cell unit.
3. Remove the two screws and
remove the bracket.
4. Remove the sensor gasket.
5. Flip and remove the two screws.
Then remove the lower bracket.
6. Remove the sensor gasket.
