3-2
Capter 3 Machihe disassembly
5. Pull up the front side of the case
cover to disengage.
* Reverse this procedure for assembly.
6. Remove the case cover.
3.1.2 Support and Load Cell
1. Remove the two hex screws (5
mm).
3. Remove the four screws.
2. Remove the support.
4. Slightly slide the cassette unit.
To Next Page
